機器型號/Model

KCs2512

打印技術/Print Technology

Piezo continuous drop-on demand(DOD)

噴頭類型/Head Model

RICOH GEN5/RICOH GEN6/KM H9888

噴頭個數(shù)/Printhead Quantity

2-9

墨滴大小/Drop Volume

7 Pl./5 Pl.

顏色配置/Coloroptions

CMYKLcLm + White + Varnish

供墨方式/Ink supply Systeme

采用真空負壓自動連續(xù)供墨Automatic continuous ink supply with vacuum negative pressure

墨水類型/INKType

UV型墨水 / Environmentalfriendly UV/LED curable ink

烘干裝置/Drying System

LEDUV燈固化/LED UVlamp Curing

平板尺寸/Flat-Bed size

2500mmx1300mm

打印厚度/Print Height

100mm/200mm(可選/optional)

打印分辨率/Print Resolutiom

600*2400 dpi

最快打印模式及效率/Print ModeandEfciency

300*900 3pass 80m/h(草圖模式/Draft Mode)

介質吸附/Dielectric adsorption

臺面真空吸附/Desktop Vacuum Adsorption

RIP軟件/RIP Software

Photo print 19 /Print Factory

硬件/Hardware

X向驅動 伺服電機/直線電機(可選)

電源要求/Power Requirement

主機220v(+/-)10%/50A/50HZ

2512機器尺寸/Machine size 2512

2200mmx4450mmx1500mm

機器重量/Machine Weight

1000kg.

環(huán)境要求/EnvironmentalRequirements

溫度/Temperature 15°℃~30°℃ 相對濕度/Relative humidity40%~80%
